Ribbon Blender Dryer Manufacturer

Capacities Available : 10 Liter to 12000 Liter

A Ribbon Blender Dryer is defined as the horizontal U shape Ribbon blender with a jacket across the U shape vessel of mixer. This design typically categorized as the 'U shape jacketed Paddle Blender machine' which is known as very versatile piece of 'MIXING + DRYING' or ' MIXING + COOLING' equipment which produces efficient mixing as well as controlled heating or cooling of the materials which are being processed in the equipment. Arvinda Industries manufacturer various capacities of Paddle Blender Dryer Machine which are often used in industries where precise temperature control is essential during the mixing process, such as in the pharmaceutical, specialty chemical, and food industries.

• U Mixing Chamber: This Equipment has U shape mixing chamber the materials are loaded into and mixed with each other. U trough contains the spiral helical type agitator shaft and provides the space for efficient blending and drying.


• Ribbon Agitators: As per the requirement either 'Arvinda Single Helical Ribbon Agitator' or 'Arvinda Double Helical Ribbon Agitator' is provide as a central agitator shaft. Ribbons paddles are fixed on ribbon arm which are attached to a central shaft. Both Outer as well as Inner Ribbon while under the shaft rotation moves the materials within the mixing chamber, helping uniform mixing.


• Heating/Cooling Jacket: The Main feature is U shape jacket around outer periphery of mixing chamber and is designed for the circulation of heating or cooling fluids. The jacketed walls provide temperature control for the materials within the mixing chamber.


• Heating/Cooling Medium: A heating or cooling medium, such as steam, hot water, or thermal oil, is circulated through the jacket to control the temperature of the materials.


• Temperature Control: Temperature control and Automatic Temperature control mechanisms regulate the flow and temperature of the heating or cooling medium in the jacket, ensuring precise temperature management.


• Insulation: The jacketed mixing chamber is often insulated by various types insulation material so as ensure safety of manpower and also to prevent heat loss or gain from the surroundings.


• Gear-Motor and Shaft: The central shaft with the ribbon agitators is connected to a gear-motor drive that drives the rotation of the paddles.


• Controls: Various features of control panel such as Temperature controllers, speed controllers, and other instruments are used to set and monitor mixing speed and temperature.

• Precise Temperature Control: Suitable for accurate temperature control, for consistent and controlled heating or cooling of the materials during the mixing process.


• Uniform Mixing: Paddle agitator creates uniform mixing of feed incidents while the jacket maintains the desired temperature via use of heating/cooling medium.


• Efficient Heat Transfer: Along with mixing, the Heat transfer is also being achieved for processing the material with desired level of temperature


• Time Savings: This combine action of Mixing along with temperature control can be achieved in single equipment, which saves overall time, manpower, energy, and improved production yield in cost effective way.


• Reduced Contamination Risk: Enclosed mixing and jacketed temperature control help prevent contamination and maintain product quality.

• Widely preferred in pharmaceutical, food, specialty chemical industries for efficient mixing and drying of feed material.


• Suitable especially in the applications where temperature-sensitive components need to be blended under controlled conditions.


• Mixing of every day products like pharmaceutical, Herbal, Ayurvedic formulation, food ingredients, such as chocolate or dairy products, Seeds, Nuts, Grains, Agro feed, Animal Feed Products while maintaining specific temperature ranges for optimal texture and flavor.


• Blending chemicals in the chemical industry where precise temperature control is crucial for reaction rates and product quality.
